STAR TSP143III USB Printer Overview
Star revolutionises POS terminal Device Choice with DIRECT iPad Receipt Printing via standard iPad /iPhone / iPod USB – lightning cable.
Today retailers and restaurateurs have the choice of the traditional POS terminal or new and innovative tablet POS providing the flexibility and mobility increasingly required within retail and hospitality environments.
However, concern for communication and connectivity issues has resulted in retailers
being reticent to take advantage of the cost-savings of mobile tablet POS.
Managing a large estate of multiple tablets and paired Bluetooth devices means that it can be operationally difficult to maintain the right connection between the right peripherals and devices. The Star TSP143IIIU POS printer changes all this.
As well as working with a traditional POS terminal, this printer can also connect directly to an iPad or iPhone using the Apple supplied lightning cable for reliable USB communication.
As a result, the usual Bluetooth or WiFi / wired LAN set-up issues around pairing, network infrastructure, connectivity etc. are eliminated.
No other stand-alone POS printer can achieve this today!
 |
USB cable interface – USB cable included |
|
FAST 250 mm/second print speed |
|
WPS easy set-up |
|
DROP-IN & Print paper loading |
|
NEW guillotine auto cutter ( 2 million cuts) |
|
CONVENIENT internal power supply |
|
THIN paper capability (0.053 to 0.085mm) |
|
DEVICE CHARGING – Simultaneous Data/Charging connection to iPad/iPhone/iPod |
|
NEW AllReceipts Digital Receipting from Star Cloud Services |
|
Unique futurePRNT software included |
The new TSP143III USB works happily with Star’s new Digital Receipting service AllReceipts.
The printer immediately sends an image of the printed receipt with full colour promotional image or terms & conditions to the Cloud for anonymous retrieval by the customer – no need for phone number or email address.
Retailers will now be able to receive instant feedback on customer satisfaction as well as provide promotional material on their customer’s smartphone.
The customer, in turn, will have an exciting new mobile App to manage their receipts digitally by date, type or retailer with backup & print facility.
Online, realtime device management also included.
Read More Here: www.starcloudservices.com
TSP143III USB Specifications
| Print Method / Resolution | Direct Thermal / 203 dpi |
| Print Speed | 250 mm/second |
| Paper Width | 80 mm (58 mm using paper guide) |
| Print Width | 72 mm (80 mm wide) 51 mm (58 mm wide) |
| Paper Thickness | 0.053 – 0.085 mm |
| Paper Roll Diameter | up to 83 mm |
| Auto Cutter | Partial cut with Guillotine (Cutter life 2 million cuts) |
| Print on Disconnection | Real Time Network Status Print Message |
| Power Supply | Internal – cables included – Energy Star Certified |
| Interfaces & Connectivity |
USB 2.0 plus direct, unique data & simultaneous Charging connection to iPad/iPhone/iPod with Apple supplied lightning cable |
| Emulation | Star Graphic Mode, Supports Star Line & ESC/POS™ Mode via futurePRNT software |
| Sensors | Paper End, Cover Open |
| Dimensions | 142 (W) x 204 (D) x 132 (H) mm 1.68Kg |
| Reliability (Printer MCBF) | 60 million lines/ Autocutter 2 million cuts |
| ECO Features | Top Margin 11mm; Print on Demand; Receipt Horizontal Compression 80mm width to 58mm |
| Drivers | Windows 7,8,10; OPOS; JavaPOS SDK Support for iOS, Android, & Windows; Star IO SDK for iOS & Android; CUPS Driver (Linux, MAC OS) |
| What’s included in the Box | Printer, 1.8m Power Cable, Vertical Wall Mount Kit, Sample Paper Roll, 58mm Paper Guide, Power Switch Cover, Set Up Instructions, 1m USB Cable (Lightning cable supplied with Apple device) |
| Options | Splash Proof Cover – SPC-100/650; Desk Boot – VS-T650/100 (desk boot); Integrated Buzzer – BU01-24-A |
| Star Cloud READY | Brochure in box to enable free access to Star Cloud Services Providing full digital receipting to your customer’s mobile device. This is completely anonymous and you do not have to ask for your customer’s email address or cellular phone number. You are also able to place full colour advertisements on the reverse side of your customer’s receipt. |
| Digital Receipting | AllReceipts with Customer App (www.SMCS.io) |
| Device Management | Provides real time status across the installed base of printers with refreshed error status notification on a comprehensive cloud based dashboard |
| Customer Satisfaction | Customer Satisfaction survey included in App for instant feedback |
| Engage Now | Logo link to retailer URL to close communication loop |
| Receipt Flip | Receipt Reverse – Opportunity to use full colour advertising and promotion on customer’s smartphone |
| futurePRNT Software | Enhanced Receipt Design tools for Windows that work above the retailer’s software. Sophisticated, easy-to-use tools including Image Import Tool, Receipt Pre-View Tool, Multiple Coupon Marketing & Text Triggered Tools, Auto-Text Reversal Tool for vertical use, Journal & Multi-Copy Tool can all be set up on one terminal and sent to all other terminals across the estate via a .XML file removing the need to configure each printer before installation, saving both time and money. |
| Warranty | 12 months – users register free for 3 years |
| Part Numbers | Grey Model : TSP143IIIU-GRY Ultra White Model : TSP143IIIU-WHT (Indent Only) |
| For further information | Sales Call +612 8788 1500 or Contact Us |
